| 基本特性 Basic Features | |
| Package | LGA |
| Dimension (mm) | 48*48*3.7 |
| 5G NR | n1/3/5/8/28a/41/78/79 |
| LTE | B1/3/5/8/34/38/39/40/41 |
| WCDMA | B1/8 |
| GSM | 900/1800 |
| V2X | NA |
| Operating Voltage | 3.8V~4.2V, Typical 4V |
| Operating Temp | -40~+85°C (ecall+95°C) |
| 关键功能 Key Functions | |
| NR (Mbps) | 4500(DL)/925(UL) |
| LTE (Mbps) | 1600(DL)/200(UL) |
| WCDMA(Mbps) | 42(DL)/5.76(UL) |
| GSM(Kbps) | 296(DL)/236.8(UL) |
| V2X(Mbps) | NA |
| 功能 Functions | |
| UMT | ● |
| A/B Dual system | ● |
| FOTA | ● |
| Voice | ● |
| SMS | ● |
| DSDS |
Optional |
| DSDA |
Optional |
| GNSS | GPS/GLONASS/Galileo/BeiDou/QZSS |
| Multi Frequency GNSS (L1+L5) | Optional |
| Dead Reckoning | Optional |
| RTC | Optional |
| eCall | ● |
| eSIM | ● |
| Temperature Management | ● |
| AI | NA |
| NTN | Optional |
| 安全 Security | |
| TrustZone | ● |
| Secure Boot | ● |
| SE-Linux | ● |
| 接口 Interfaces | |
| USB | USB3.1/USB2.0 |
| PCIe 3.0 | x 2 |
| SDIO | x 2 |
| UART | x 5 |
| SPI | x 3 |
| I2S/PCM | x 2 |
| I2C | x 2 |
| SIM | x 2 |
| RGMII | x 1 |
| SGMII | x 1 |
| USXGMII | x 1 |
| ADC | x 4 |
| GPIO | x 16 |
| Antenna | x4 (蜂窝)+1(GNSS) |
| 认证 Certification | |
| Regulation | CCC*/SRRC*/NAL |
| 备注 | *全球版本可选（GL: optional） |
